Diy Bottle Filling Machine

Product Application


This machine is suitable for measuring and weighing filling and filling of fluid 10-50Kg. Automatically complete the counting into the bottle, weighing the weight of filling, conveying a bottle of a column operation. Especially suitable for water agent, edible oil, lubricating oil, etc., is the ideal packaging machine for food, medical and chemical industry.

Filling   valve   head
6 heads
4 heads
 production capacity
≦600Barrels per hour(With water as medium)
≦400Barrels per hour(With water as medium)
Applicable to bucket size
length:160mm~360mm;          width:140mm~260mm ;              height :250mm~500mm
Outline dimension
2500mm(length)x1700mm(width)X2300mm(height )
Barrel diameter
≥Φ40mm
Packaging specifications
10L~50L
 Error
≦±0.2%
Power supply
220V 50Hz
Host power
2000W
 Prepare  gas  source
0.5Mpa-0.65Mpa (Clean and stable gas source)
Machine weight
About 850kg

Main Features


1) Simple structure in linear type ,easy in installation and maintation.

2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

3)The machine adopts programmable controller (PLC), touch screen for operation control, easy to use.

4) Running in a high automatization and intellectualization,no pollution

5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .

Machine Parts


Name:Weighing cell

Brand: NPACK

Original: China

High sensitivity, High accuracy of weighing ,Easy to use,

Convenient for cleaning

Main Features

Name: Cylinder
Brand: AirTAC
Original: China
Quality assurance, corrosion resistance, compact size,CE



Quick Details


Type: Filling Machine
Condition: New

Application: Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical
Packaging Type: Bags, Barrel, Bottles, Cans, Cartons, Case, Pouch, Stand-up Pouch
Packaging Material: Glass, Metal, Paper, Plastic, Wood
Automatic Grade: Automatic
Driven Type: Electric
Voltage: 220V/380V
Power: 1.5kw
Place of Origin: Shanghai, China (Mainland)
Brand Name: NPACK
Dimension(L*W*H): 1800*1600*2000
Weight: 850KG
Certification: ISO
After-sales Service Provided: Engineers available to service machinery overseas
304stainless steel:316stainless steel
